2*15" HIGH POWER LONG- THROWN WOOFERS, PUNCHY BASS WITH PRECISION AND CLARITY

Well aranged linear array speaker providing first class audio performance.

X TEN SYSTEM

DESCRIPTION:

The X TEN SYSTEM is a meticulously engineered linear array loudspeaker, delivering exceptional audio performance tailored for live concerts, touring applications, fixed installations, and rental companies. Featuring premium transducers, the X-TEN offers flexible horizontal coverage options of 70° × 25°, 90° × 25°, or 100° × 25°, ensuring precise dispersion control for a variety of acoustic environments.



Capable of achieving a maximum sound pressure level (SPL) of up to 131 dB, the X TEN SYSTEM is housed in an ultra-compact enclosure that incorporates three high-efficiency 9" low-frequency drivers and a 3" compression driver coupled to a precision waveguide for superior high-frequency projection.



The X TEN SYSTEM’s versatile configuration options and pristine sound reproduction make it an ideal solution for small to mid-sized concert venues and sound reinforcement applications.

FEATURES:

◦ 131 dB max SPL for powerful output.

◦ Flexible coverage: 70°, 90°, or 100° × 25°.

◦ 3× 9" LF drivers + 3" HF compression driver.

◦ Compact, lightweight enclosure.

◦ Standalone, arrayable, or with subwoofer.

◦ Ideal for concerts, installs, and rentals.

CHARACTERISTICS

X TEN TOP

X TEN SUB

Model

X TEN TOP

X TEN SUB

Frequency response

55Hz - 20KHz

40Hz - 320Hz

Drivers

High: 1x3” compression driver

Low: 3x9” (65mm voice coil)

2x15” LF driver

Dispersion angle

H110° H90° H70° xV25°

-

Sensitivity

97dB

103dB

Impendance

5 ohm

4 ohm

Rated power

700W

1000W

Power peak

2800W

4000W

Max SPL

131dB

139dB

Connectors

2x4-pin Neutrik Speakon

XLR + SPEAKON

Power supply

-

AC 110 - 240V / 50Hz

Amplifier power

-

8 ohms: 900W + 900W

DPS connector

-

One USB interface on front pane

Product dimensions

258 x 400 x 1050 mm

800 x 750 x 450mm (WxDxH)

Shipping dimensions

-

850 x 510 x 860mm (WxDxH)

N.W / G.W

38 kgs

59.5 kg / 63.7 kg

DRAWINGS:

DRAWINGS:

SPECIFICATIONS:

MANUAL

DOWNLOAD PDF

BROCHURE

DOWNLOAD PDF

DATA SHEET
