3pcs of 3.5’’ tweeter
semi-coaxially with a high power 8’’ woofer for better sound reproduction.
LIVE LOUD
Mic for singing and Musical instrument reinforcement available
3pcs of 3.5’’ tweeter semi-coaxially with a high power 8’’ woofer for better sound reproduction

Mic for singing and Musical instrument reinforcement available

Mic for singing and Musical instrument reinforcement available
3pcs of 3.5’’ tweeter semi-coaxially with a high power 8’’ woofer for better sound reproduction

MINI PA 10
DESCRIPTION:
The MINI PA 10 is an extra compact and lightweight multifunctional speaker. Its polypropylene cabinet is finely designed in every detail to maximize the convenience of application. An ergonomic handle and high-quality lightweight structure make it easy to move and install.
3pcs of 3.5“ cone tweeter coaxially structured above a rugged 8” woofer allows clear and transparent high frequency and rich low frequency sound reproduction. The smart cabinet design makes the speaker either be mounted on a standard speaker stand, random position or on a surface, lay down or even tilt back as a monitor.
The built-in lithium-ion batteries inside power up the speaker to continue working up to 8 hours. Two professional preamplifiers provide more comprehensive input through composite sockets or Bluetooth & MP3 players, making it suitable for a wider range of input signal options. Music can be played anytime and anywhere. The amplifier part adopts a two channel amplifier module. It achieves greater dynamic margin with a professional effector. Two UHF wireless microphones are available to sing your song at your finger tips.
FEATURES:
◦ 3pcs of 3.5’’ tweeter semi-coaxially with a high power 8’’ woofer for better sound reproduction
◦ 3 band EQ, independent volume control, reverb, echo and gain adjustment at CH2 and CH3
◦ Durable Lion batteries
◦ Battery protection board
◦ Mic for singing and Musical instrument reinforcement available
◦ Aux audio input
CHARACTERISTICS
INFORMATION
Speaker Type
Portable active speaker
HF
Three x 3.5’’ Voice Coil
LF
One x 8*
Frequency Response
60Hz-20KHz±10dB
Sensitivity
94dB
Max SPL
122dB
Speaker Power
100W+3*10W
Amplifier
Class D
Controller
MP3 & Bluetooth 5.0
Connectors
2 - XLR/TRS Combo 1
- TRS footswitch
1 - USB
1 - Type C, 2-3.5MM input
1 - TRS monitoring output
